XCF/KYF Flotation machine

Structure

KYF Flotation machine

1. impeller  2. air distributor  3. Stator  4.barrel  5. principal axis  6. Bearing

XCF and KYF flotation cell are advanced air-inflation, mechanical agitation flotation devices. It is developed mainly reference the flotation devices that currently used in mines. It is designed fully considered about the flotation charactors and processing conditions, absorb the advantages of mechanical agitation flotation cells, avoid the shortcomings and defects of the other devices.

Advantages

Advanced design of structure; reliable operation; lower energy consumption; the flotation cell adopts U-shaped tank, hollow shaft inflatable and suspension stator, using a new impeller, this is a kind of cone impeller with blade sloping, similar to the high speed centrifugal pump wheels, large pulp capacity, small pressure head, low energy consumption and simple structure.

Good effect of air dispersion, impeller works as a centrifugal pump, ensures the solid particles suspend well. Easy to operate and maintain.

Parameters
